TF-Nova Lidar

TF-Nova Lidar

Benewake offers the industry’s first one-dimensional area sensing solution with a line-pattern laser beam. It features a compact design, multiple interfaces, a waterproof lens, and versatility for both indoor and outdoor use. The comprehensive command set ensures seamless integration. Mounted next to the camera lens, TF-NOVA projects a line-pattern laser beam to enhance perception and distance measurement. When the camera is pointed at an object, TF-NOVA activates automatic focal length adjustment for fast and accurate focusing, quickly achieving precise distance.

Line Pattern Laser Beam:

TF-NOVA has a 14°×1° field of view and can detect a 25×1.7 cm2 area from a distance of 1 m, similar to two horizontal chopsticks.

• Range: 0.1m ~ 14m

• Field of view: 14°(H)*1°(V)

• Frequency: 1Hz~ 900Hz

• Weight: ≤5g



Compact Size:

Its size is 26.5x21.05x12mm³ and its volume is about 7cm³, smaller than AA battery. It provides great convenience and flexibility for system integration.

• Dimension: 26.5x21.05x12 mm³

• Accuracy: ±5cm @0.1-4m

• Working Temperature: - 25 ℃~+ 70 ℃

Stable Detection in Indoors and Outdoors:

TF-NOVA reliably detects a 5cm target with 10% reflectivity at 2m distance in both bright sunlight and low light. In summer, black vehicles can be detected at 2m distance.

Multiple Interfaces:

TF-NOVA supports both standalone and network-based operations. Additionally, it can be configured for I/O output mode, significantly reducing data processing workload. It also supports UART and IIC interfaces.
