Sunline 853D 3A Soldering Iron Station
Sunline 853D 3A Soldering Iron Station is a product that brings together the needs of technical services in electrical and electronic applications where speed and practicality are important. Combining technology, compact design and all necessary devices for repair, the soldering iron station has 3 functions. This device, produced with an innovative design by integrating an adjustable 15V/2A DC power supply, hot air station and soldering station, provides ease of use. You can operate the 3 functional features integrated into the case independently thanks to the "dual core processor". Combined DC Power Supply has the feature of detecting and measuring the RF signal strength through the LED indicator, as well as providing power for the mobile phone.
Sunline 853D 3A Soldering Iron Station Application Areas:
- Electronic Product Assembly
- Product Development and Scientific Research Laboratories
- Electrical Soldering Works
- Electronic Maintenance Products
- All Kinds of Electronic Manufacturing and Repair Institutions / Organizations / Schools Providing Skill Training
- Mobile Phone or Computer Repair, Maintenance, Repair Works
- At the University, Technical Laboratories or R&D Laboratories
Sunline 853D 3A Soldering Iron Station Technical Specifications:
- Model: 853D+
- Power Consumption: 720W±10%
- Storage Ambient Temperature: 20-80 °C
- Ambient Heat Operation: 0 ~ 50°C
- Hot Air Station Section:
- Airflow Type: Brushless Fan
- Blowing Flow: 120L/min
- Temperature Range: 100°C-480°C
- Temperature Stability: ±2°C
- Display Type: LED
- Arm Cable Length: 100 cm
- Blowing Arm Warmer: 74Ω
- Soldering Station Section:
- Power Consumption: 75W ± 10%
- Temperature Range: 200°C-480°C
- Temperature Stability: ±1°C
- Grounding Voltage: 2 mV
- Earth Impedance: 2 ohms
- Display Type: LED
- Arm Cable Length: 100 cm
- Arm Warmer: High Power Warmer
- Calibration Mode: PID Digital Programmed Calibration
- DC Power supply Section:
- Output Voltage: DC 0-15V
- Output Current: 0 ~ 3 (Adjustable)
- Load stability: 0.01 ± 2mV
- Temperature Coefficient: 300 ppm / °C
- Ripple dB: 1 mvrms
- Display: LED
- Size: 255x188x125mm
- Weight: 5.5 kg
Brushless Fan Advantages:
- High Efficiency
- Quiet Operation
- Long life
- More Torque
- High Moment Volume Ratio
- Linear Moment Velocity Relationship
- Does not create electrical voltages
