Raspberry Pi 4 - 1GB

What is Raspberry Pi?

Raspberry Pi is a single board computer. This means that all units required for a computer such as processor, RAM memory, inputs/outputs are gathered on a single circuit board. Thanks to its small design and compact structure, it is possible to use these computers in our robotic projects, smart home systems, embedded systems, kiosks, and even as desktop computers by connecting peripherals such as keyboard/mouse and screen. In cases where computers such as Raspberry Pi, microcontroller boards such as Arduino are not enough and more than one operation is required at the same time(exp. mobile robot that broadcasts images over the web) preferable. Raspberry Pi, as well as Linux operating systems game machine, media center, network device t has the ability to run a large number of ready-made systems specially developed to perform functions such as

What Can I Do With Raspberry Pi?

Using Raspberry Pi, it is possible to make software projects using almost any programming language that can run on Linux. It is possible to develop software on Raspberry Pi with languages such as Python, which is easy to understand and use for beginners, block-based Scratch specially developed for children, and Java or C/C++ for more advanced users. By using the pin connections (GPIO pins) on the Raspberry Pi, it can flash LED light, control the movements of electric motors, read different types of sensor data, Raspberry Pi compatible cameras ı you can make your own IP camera by using it and even turn on and off devices that work with 220V AC with additional modules such as a relay card. If such projects do not interest you, you can have a system with very low power consumption by literally turning your Raspberry Pi into a computer by connecting a keyboard/mouse and screen.

How to Install raspberry Pi 4?

Before you start using the Raspberry Pi 4, you need to install the operating system on an SD card. Step-by-step operating system installation from this page on our blog veya From our YouTube video you can easily complete it.



Raspberry Pi 4 İnceleme Videosu


Raspberry Pi 4 Features (Differences with Raspberry Pi 3B+)

Raspberry Pi 4 comes with a lot of innovations on its predecessor, the Raspberry Pi 3B+. The first striking feature is that the RAM memory of 1GB and LPDDR2 type in the previous model comes with 2GB, 4GB and 8GB LPDDR4-3200 options. In addition, Raspberry Pi 4's 4-core 64-bit processor runs at a frequency of 1.5GHz. The VideoCore IV graphics unit in the Broadcom BCM2711 SoC IC operates at 500MHz clock frequency. Besides these improvements under the hood, Raspberry Pi 4 has 2 high-speed USB 3.0 ports and 2 micro-HDMI connections for 4K 60fps video output. The power input socket of Raspberry Pi 4, which needs more power than previous models, is now USB-C type.



ROther Materials Required for Raspberry Pi 4:

To start using your raspberry Pi 4 immediately, you will need the following items:

If you wish, you can find the original licensed case compatible with your Raspberry Pi 4 by clicking here.

Raspberry Pi 4 Technical Specifications:

  • processor: Broadcom BCM2711, quad-core Cortex-A72 (ARM v8) 64-bit SoC @1.5GHz
  • Memory: 1GB, 2GB, 4GB models
  • Connection: 2.4GHz and 5.0GHz IEEE 802.11b/g/n/ac wireless LAN,
  • Bluetooth 5.0, BLE. Gigabit Ethernet, 2 x USB 3.0 ports and 2 x USB 2.0 ports
  • Input: Standard 40-pin GPIO (backward compatible)
  • Video and Audio: 2 xmirco HDMI ports (support up to 4Kp60)2-line MIPI DSI Display port2-line MIPI CSI
  • Camera port4-pole stereo audio and composite video port
  • Multimedia: H.265 (4Kp60 decode), H.264 (1080p60 decode, 1080p30 encode), OpenGL ES, 3.0 graphics


Important Note:
GPIO pins on Raspberry Pi operate at 3.3V. Not compatible with 5V.

Raspberry Pi 4 Pin Layout - Is there any difference between 3+ in pinout?

Raspberry Pi 4 has a standard 40-pin GPIO connection, which has been used since Raspberry Pi Model B+. In this way, it can work fully compatible with your existing shield cards and other hardware.



Documentation and Useful Links:
