By using this shield that has TLC5940 integrated on it, you can have 16 extra PWM output on your Arduino.Each of 16 output, come together with VCC and GND pins that are suitable for soldering triple standard 0.1" header. It is compiable to use with servo motors and brushed/ brushless RC speed control units(ESC). It is ideal for multiple LED driving projects.
To drive the servo motors, 2.2k pull-up resistors are added on every PWM output. There is an external power input on the card for feeding servo motors.
P.S: Even though every triple connector has standard side by side 0.1" header sequence, distance between connectors are a bit increased to make sure that servo connectors are seated well.Documents:
