Adafruit Bluefruit LE UART Friend - Bluetooth Low Energy (BLE)
- Payment Options
- Comments (1)
- Suggestion Box
You can use this board, which has the Bluetooth Low Energy (BLE) feture, in robotic or electronic projects to gain them wireless communication function. You can communicate your projects with Android or iOS devices by using the BlueFruit app.
You can use this board in wireless serial communication applications by connecting it to your microontroller's UART output. Also it has the ability to define and manipulate your own GAT services and characteristics, or change the way that the device advertises itself for other Bluetooth Low Energy devices to see. You can also use the AT commands to query the die temperature, check the battery voltage, and more. Using the Bluefruit iOS app or Android App, you can quickly get your project prototyped by using your iOS or Android phone/tablet as a controller. The app has a color picker, quaternion/accelerometer/gyro/magnometer or location (GPS), and an 8-button control game pad. The Bluefruit can also act like and HID Keyboard, can become a BLE Heart Rate Monitor or turn into a UriBeacon. You can use Andoid or iOS devices to get firmware updates for the board.
- ARM Cortex M0 Core Running at 16MHz
- 256KB Flash Memory
- 32 KB SRAM
- UART at 9600 Baud with HW Flow Control
- 5V Operating Voltage Option
- On-Board 3.3V Voltage Regulation
- Bootloader that supports OTA firmwre updates
- Easy AT command set to get up and running quickly
- Dimensions: 21 mm x 32 mm x 5 mm
- Weght: 3.4 gr
Click here for example code and Arduino library.
