Trimpots, voltage divider and contrast adjustment circuits are used in circuits which need to be adjusted precisely and resistance adjustment is not required.

Technical specifications:

  • Resistance Value:2K
  • Trimpot Type: Multi Turn Horizontal
  • Number of Turns: 15
  • Resistance Change: Linear
  • Total Resistance Tolerance:  10%
  • Rated Power: 0.75W
  • Max Operating Voltage: 500V DC
  • Operating Temperature: -55C to +125C
  • Stop torque:  >0,36(max)
  • Dimensions: 9.53mm x 4.83mm x 10.03mm

Technical Drawing:



Technical Documents:

17968
2K Multi-turn Trimpot (Horizontal) - 3006P-1-202
2K Multi-turn Trimpot (Horizontal) - 3006P-1-202
:
7.05 TL + VAT
:
8.46 TL
