STM32 Processor Kit NUCLEO-F446RE

STM32 Development Board NUCLEO-F446RE

The STM32 Nucleo-64 NUCLEO-F446RE is a flexible and powerful development board designed for electronic engineers, developers, and makers to try out new ideas and rapidly build prototypes. Featuring the STM32F446RE microcontroller with a high-performance ARM Cortex-M4 core, this board delivers superior performance in demanding embedded system projects with its 180 MHz processing speed.

Offering an excellent structure in terms of expandability, the board provides both Arduino Uno V3 connectivity support and ST morpho multi-pin headers together. This allows for easy integration with countless sensors and modules on the market. Thanks to the integrated ST-LINK/V2-1 programmer and debugger on the board, you can upload your codes and test your system directly via a USB cable without the need for any external module.

Key Features:

• High-Performance Core: Easily performs digital signal processing and heavy calculations thanks to the FPU (Floating Point Unit) supported ARM® Cortex®-M4 processor running at 180 MHz.
• Integrated Programmer (ST-LINK/V2-1): Offers drag-and-drop programming, a virtual COM port, and debugging support without needing an external programmer device.
• Extended Compatibility: Fully compatible with Arduino Uno V3 shield boards, while providing full access to all microcontroller pins via ST morpho headers.
• Flexible Power Options: Can be powered directly via USB VBUS (5V) or external sources (3.3V, 5V, 7V-12V) depending on your project requirements.
• Rich Software Support: Works seamlessly with STM32Cube HAL (Hardware Abstraction Layer) libraries, various software examples, and the ARM mbed™ online ecosystem.

Technical Specifications:

Application Areas:

• Motor drive control systems and industrial automation.
• Advanced robotics projects, drones, and autonomous system controllers.
• Smart home appliances and IoT (Internet of Things) sensor networks prototyping.
• University-level digital signal processing (DSP) and hardware education laboratories.
