STM32 Development Board NUCLEO-F303RE

STM32 Development Board NUCLEO-F303RE

The STM32 Development Board NUCLEO-F303RE is a development platform designed by STMicroelectronics for the STM32F3 series microcontrollers. It is equipped with the STM32F303RE microcontroller featuring an Arm® Cortex®-M4 core, making it an ideal solution for signal processing, motor control, and industrial applications.

Thanks to the integrated ST-LINK/V2-1 debugger and programmer, the board allows programming and debugging without the need for external hardware. Arduino™ Uno V3 and Morpho pin compatibility enables the use of a wide range of expansion boards and shields.

Compatible with popular development environments such as STM32CubeIDE, IAR Embedded Workbench, and Keil MDK-ARM, the NUCLEO-F303RE is a flexible and powerful solution for education, R&D, and professional embedded system projects.

STM32 Development Board NUCLEO-F303RE Technical Specifications:

• STM32F303RE microcontroller with Arm® Cortex®-M4 core

• Maximum operating frequency of 72 MHz

• 512 KB Flash memory

• 80 KB SRAM

• On-board ST-LINK/V2-1 debugger and programmer

• Arduino™ Uno V3 and Morpho pin compatibility

• USB virtual COM port and debug support

• Compatible with STM32Cube software libraries and example projects

Useful Links / Documents:

• STM32F303RE Datasheet
• NUCLEO-F303RE Documentation
