Digital Panel Voltmeter AC 30-500V

Features:

• Adopting the capacitance step-down principle design, not suitable for high frequency occasion
• Used to monitor the household voltmeter, also applied to other AC voltmeter measuring.
• Good stability and high measurement accuracy.
• With trimmer potentiometer.
• Easy to read, install and use.



Specification:

• Model: YB27A

• LED digit: 0.56" digit

• Display Color: Red, Blue, Green

• Supply Voltage: No Need (two-wire system)

• Measuring Range: AC30-500V

• Accuracy: 1%

• Min resolution: 1V

• Input impedance: >1MΩ

• Measuring speed: ≥2 times/S

• Working temperature:-10-+50℃

• Working humidity: 10-80%(non-condensing)

• Working pressure: 80-106kPa

• Wire length: 150MM

• Housing color: Black

• Product Size: 48x 29 x21 mm
