TP4056 Lityum Pil Şarj Modülü

TP4056 Lithium Battery Charger Module - Micro USB Input

The TP4056 charging module is one of the most popular and cost-effective solutions for safely charging single-cell (3.7V) Lithium Polymer (Li-Po) or Lithium-Ion (Li-Ion) batteries. Thanks to the onboard Micro USB input, you can easily charge your batteries via any smartphone charger or a computer's USB port.

The module utilizes the constant current/constant voltage (CC/CV) charging method and automatically terminates charging when the battery is full to preserve battery lifespan. The dual-color LED indicator provides real-time status (Red: Charging, Blue/Green: Fully Charged). Its compact design is perfect for portable projects, DIY flashlights, and power supply applications.

Key Features:

• Smart Charge Management: Secure CC/CV cycle powered by the TP4056 chipset.
• Micro USB Support: Easy power input using common charging cables.
• Visual Feedback: Integrated status LEDs for monitoring the charging process.
• Adjustable Current: Charge current can be customized by changing the onboard resistor (Default 1A).
• Compact Form: Minimal dimensions suitable for various enclosures and tight spaces.

Technical Specifications:
