SSR 10DA 10A Solid State Relay

SSR 10DA 10A Solid State Relay

The SSR 10DA 10A Solid State Relay is a semiconductor-based relay that allows switching AC loads with a DC control signal. Since it does not contain mechanical contacts, it operates silently, is resistant to vibration, and provides a long switching lifespan. It is widely used for controlling AC loads such as heaters, resistive elements, lamps, and similar devices.

Compatible with Arduino, PLC, and industrial control systems, this model enables safe control of high-voltage AC loads using a low-current control signal. The built-in LED indicator allows easy monitoring of the trigger status.

SSR 10DA 10A Solid State Relay Technical Specifications:

• Model: SSR-10DA

• Relay Type: Solid State Relay (Semiconductor switching)

• Control (Input) Voltage: 3-32V DC

• Control Current: 7-20 mA

• Output Voltage: 24-380V AC

• Maximum Load Current: 10A

• Switching Type: DC control / AC output (Zero Crossing)

• Turn-On / Turn-Off Time: ≤10 ms

• Off-State Leakage Current: ≤2 mA

• Dielectric Strength: 2500V AC

• Operating Temperature: -20°C ~ +80°C

• Built-in LED status indicator

• Mounting Type: Screw terminals, case suitable for heatsink mounting
