reComputer J1010

reComputer J1010

The reComputer J1010 is a compact edge computer built with the NVIDIA Jetson Nano 4GB production module and built with advanced AI embedded systems Jetson Nano and a Seeed reference carrier board (Jetson-10-1-A). It comes with 128 NVIDIA CUDA® cores providing 0.5 TFLOPs (FP16) to run AI frames and applications such as image classification, pose estimation, object detection, speech processing, intelligent analytics.

It also includes built-in microSD card slot, 1*USB 3.0, 2*USB2.0, HDMI, M.2 Key E for WiFI, LTE and Bluetooth, RTC, Raspberry Pi GPIO 40- and J101 carrier card. Jetpack 4.6.1 is pre-installed on the reComputer J1010 so you just need to plug in a USB C 5V/3A power supply, keyboard, mouse and ethernet cable and you are ready to start your AI journey.

reComputer J1010 Features:

• Hand-sized edge AI full system.
  Ready for development and distribution.
  power efficiency.
  Built-in interfaces can be re-expanded with the computer case.
  It can be mounted on the wall.

reComputer J1010 Specifications:

• Size: 130mm x 120mm x 50mm
• Power supply: USB Type C 5V - 3A
• Storage: 16GB eMMC
• SD Card Slot: Included (Carrier Card)
• Video Encoder: 4K30 / 2x1080p60 / 4x1080p30 / 4x720p60 / 9x720p30 (H.265 - H.264)
• Gigabit Ethernet: 1*RJ45 Gigabit Ethernet Connector (10/100/1000)
• USB:
• 1 * USB 3.0 Type A;
• 2 * USB 2.0 Type A;
• 1 * USB Type C for device mode;
• 1 * USB Type C for 5V power input
• CSI Camera Connection: 2*CSI Camera (15 exposures, 1mm pitch, MIPI CSI-2)
• Display: 1 * HDMI Type A
• M.2 Key E: 1*M.2 Key E
• Fan: 1* FAN (5V PWM)
• Multi-Function Port: 1* 40-Pin headerbaşlık
