Hantek 6022BL 20MHz 2 Channel USB PC Oscilloscope

Hantek 6022BL 20MHz 2 Channel USB PC Oscilloscope

The Hantek 6022BL is a compact USB oscilloscope designed for PC-based operation, featuring a 20MHz bandwidth and a 48MSa/s sampling rate. Powered directly via USB, this model offers a practical and portable measurement solution for laboratory, educational, and field applications.

In addition to its 2-channel oscilloscope structure, the Hantek 6022BL includes a 16-channel logic analyzer, allowing simultaneous analysis of analog and digital signals. This makes it well suited for testing and debugging microcontrollers, digital circuits, and communication protocols.

Its durable aluminum alloy enclosure provides both an elegant appearance and long-term reliability. The USB 2.0 interface eliminates the need for an external power supply. Compatible with Windows operating systems, the software supports FFT analysis, automatic measurements, advanced triggering options, and waveform recording features for comprehensive signal analysis.

Hantek 6022BL Technical Specifications:

• Oscilloscope bandwidth: 20MHz

• Channel count: 2 Analog + 16 Logic

• Maximum sampling rate: 48MSa/s

• Memory depth: 1M

• Vertical resolution: 8-bit

• Input impedance: 1MΩ / 25pF

• Trigger sources: CH1, CH2

• Supported analyses: FFT, automatic measurements, cursor measurement

• Connection interface: USB 2.0

• Operating system support: Windows 7 / 8 / 10

Useful Links / Documents:

• Hantek 6022BL User Manual
• Hantek 6022BL Driver
• Hantek 6022BL Software
• Hantek 6022BL SDK

Similar Products:

• Oscilloscopes
