Co Print KCM Set
Fiyat
:
10,829.99
TL + VAT
KDV Dahil Fiyat
:
12,995.99
TL
Money Order Price :
12,736.07
TL
%2 Discount
Out Of Stock
Notify me when its in stockCo Print KCM Set
The KCM Set is a third-party upgrade kit specifically designed for multicolor printing. It offers an advanced print head and supports the control of up to four extruders. This enables Klipper-based 3D printers to achieve multi-filament printing capability.
Co Print KCM Set Product Information:
KCM Set consists of advanced components designed to elevate your Klipper-based 3D printer.
- ChromaHead:ChromaHead is an advanced print head that enables fast and multicolor printing for 3D printers. It includes printable mounting parts for Sigma profiles, linear rails, and rods, making it compatible with 90% of 3D printers on the market. It features a filament cutting module, a Direct Drive extruder module, a ChromaHotend, a Head Control Board, a Filament Calibration Sensor, and cooling systems.
- Klipper Chroma Modülü: This module is the control unit required to connect ChromaHead to a 3D printer. It can also drive up to four extruders. It features a Type-C connection and communicates with the printer via a USB port.
- CX-I Extruder: It is a high-torque extruder that ensures consistent filament feeding and reliable extrusion. Optionally, you can enhance your setup with the Extended Chroma Module (ECM), allowing access to up to 20 colors and enabling the creation of complex multicolor prints.
Co Print KCM Set Technical Specifications:
KCM Technical Specifications:
| Extruder Control: 4 Extruder | ECM Support: Yes (up to 20 color) | ChromaHead Support: Yes | Power Input: 24V - 5A |
| Firmware Support: Klipper | Integrated Card: KCM Board | Weight: 86g | Package Dimension: 107,5x185,5x92mm |
|
Connection: Type-C |
Sockets: ChromaHead, 4X Extruder | Cover: ABS Plastic | Cooling: Went Channels |
ChromaHead Technical Specifications:
|
Extruder Motor: Pancake Nema 17 |
Extrusion: Direct Drive |
Calibration:Proximity Sensor | Temperature Range: 0-300°C |
| Flow Rate: 24 mm³/s | Filament Cutter: Yes | Cutting Torque: 10KG | Cutter Knife:Japanese Hardened Steel |
| Dual Drive: Yes | Sockets: ChromaHead Connection | Mechanical Support: Lineer, Sigma, Mill | Material Capacity: 8x Filament Slot |
| Cooling: 1X Blower, 1X Snail,1X 40x40 |
Integrated Card: Head Control Card |
Cover Connection: Magnetic | Weight: 400g |
| Package Dimension: 107,5x185,5x92mm | Supported Filaments: PLA, ABS, TPU, PETG, PLACF, Wood, Soluble | Fast Printing: 600mm/s |
CX-I Extruder Technical Specifications:
- High Torque Motor: A powerful motor that ensures smooth and reliable filament feeding.
- Dual-Drive Gear Mechanism: Ensures smoother and more stable filament advancement, which improves print quality.
- High Step Count: A motor with a high step count for precise filament feeding.
- High-Speed Printing Support: Maintains stability and ensures high-quality prints even during fast printing processes.
- Compatible with ChromaSet and KCM Set.
- Durable Build: Designed for industrial and professional use, offering a long-lasting and robust structure.
Package Contents:
The KCM Set consists of three different types of boxes. The first is the KCM Box, which includes one adapter, one Type-C cable, and the KCM device.The ChromaHead Box contains the ChromaHead device, a metal 8-in-1 module, a head connection cable, a Sigma mounting bracket, a material set, and the necessary screws.The CX-1 Extruder Box includes one extruder, one Nema 17 stepper motor, a 1.5-meter PTFE tube, and a motor cable. In total, the set comes with four CX-1 extruders.
