Bakon BK3600S High Frequency Soldering Iron Station - 200W

Bakon BK3600S High-Frequency Soldering Station - 200W

The Bakon BK3600S features three different solder feeding modes: semi-automatic, manual, and automatic. The solder feeding speed can be adjusted according to your soldering requirements.

With its 200W power, the BK3600S high-frequency soldering station uses high-frequency eddy current heating technology to provide strong and reliable lead-free soldering. In addition to general applications, it is also suitable for multilayer boards, bare terminals, wide joints, and other demanding conditions.

When you pause your work and place the soldering handle on the stand, the station automatically stops heating and starts the cooling process. Thanks to the automatic sleep sensor, the station then switches to sleep mode, saving energy and extending the overall service life of the unit.

For your device and personal safety, the Intelligent Soldering Station is equipped with multiple protection features such as a fault warning system, short-circuit protection, open-circuit protection, over-temperature protection, error detection, and overload protection, allowing you to use the station with confidence.

Thanks to its advanced microcomputer temperature control technology, the soldering station maintains the set temperature with a deviation of within ±2℃, ensuring stable and accurate operation. You can also set and lock upper and lower temperature limits if needed.

After replacing spare parts such as the heating element or soldering handle, any temperature deviations can be digitally calibrated via the user panel within the range of -50℃ to +50℃.

For clear visibility of detailed temperature data, the station is equipped with an elegant, large LCD digital display, allowing all information to be read easily without straining your eyes.

Bakon BK3600S High-Frequency Soldering Station - 200W Technical Specifications:

• Brand: Bakon

• Model: BK3600S

• Product Code: 12.02.36.00

• Main Unit Power: 200 Watt

• Output: 380 kHz High-Frequency AC

• Soldering Handle Power: 200 Watt

• Soldering Handle Model: LF301

• Temperature Range: 100–480℃ / 212–896℉

• Temperature Stability: ±2℃ (Static)

• Operating Ambient Temperature: -10–45℃; 45–80% RH

• Storage Ambient Temperature: -20–80℃ / -4–176℉ / 35–60% RH

• Temperature Calibration Range: -50℃ to +50℃ Digital Calibration

• Display: LED Screen

• Motor: Step Motor

• Solder Feed Speed: 0.3–20 mm/s

• Programmable Automatic Sleep: 10–60 minutes

• Solder Feed Length: 0.3–200 mm (Automatic / Semi-Automatic Mode)

• Feed Time: 0.1–30 s

• Interval Time: 0–10 s

• Solder Return Time: 0–1 s

• Solder Feed Mode: Manual / Semi-Automatic / Automatic

• Solder Wire Diameter: 0.8–1.5 mm (standard 0.8–1.0 mm; other sizes require accessory changes)

• Heating Element: VH300 High-Heat Heating Element

• Soldering Tip Model / Soldering Handle Model: 500 Series Soldering Tip Models / LF308C

• Password Lock: Yes

• Celsius / Fahrenheit Conversion: Yes

• Heating Element / Sensor / Fault Protection: Yes

• Voltage (Grounding): ≤2 mV

• Ground Resistance: ≤2 Ω

• Dimensions: 173(L) × 285(W) × 139.5(H) mm

• Weight: ≈4.3 / 4.59 kg
