AiPi-UNO-ET485 Development Board
The AiPi-UNO-ET485 is a development board compatible with Arduino® UNO, based on the powerful Raspberry Pi RP2040 microcontroller chip. Specifically designed for industrial automation projects, this board stands out with its RS485 communication module. RS485 is a communication protocol commonly used in industrial systems, providing reliable data transfer over long distances. With the integrated RS485 interface, the AiPi-UNO-ET485 can directly communicate with devices supporting this protocol (such as PLCs, sensors, and other industrial components).
AiPi-UNO-ET485 Development Board Technical Details
- Type: LoRaWAN development board; optimized for Internet of Things (IoT) projects.
- Antenna Type: External SMA antenna; ensures high performance in signal reception and transmission.
- Dimensions: 25.40 x 48.26 mm (± 0.2 mm); compact design allows for easy mounting in various applications.
- Operating Frequency: Operates within a frequency range of 410-525 MHz; enables long-range communication.
- Package: Development kit with module and antenna; compatible with factory firmware and can be controlled via serial port assistant.
- IO (Input/Output) Information: General-purpose input/output (GPIO) pins; allows connections with various sensors and components. Also includes analog input pins for reading analog signals.
- Memory: Sufficient RAM and ROM on the ASR6601 chip; suitable capacity for storing application code and data.
- Communication Protocols: I2C, SPI, UART
- Wireless Communication: LoRa Modulation: Enables long-distance communication with low power consumption. (G)FSK, BPSK, (G)MSK Modulations. Various modulation options are supported in both transmitter and receiver.
- Power Management: Designed for energy efficiency; allows long-term operation on battery power.
- Software Support: Compatible with popular development environments like Arduino® IDE and PlatformIO; provides a user-friendly development experience.
- Operating Modes: Supports different modulation and operating modes; offers flexibility for various use scenarios.
- Network Configuration: Allows easy connection and configuration to LoRaWAN networks; provides fast and reliable data transmission.
- Development Support: Offers rich documentation and resources; community forums and support groups assist developers.
- Power Requirements: Operates at 3.3V.
- Processor: ASR6601 Chip; includes a 32-bit ARM RISC microcontroller operating up to 48 MHz.
