FRDM-KL25Z Development Board
- Payment Options
- Comments (2)
- Suggestion Box
The Freedom KL25Z is an ultra-low-cost development platform for Kinetis L Series KL1x (KL14/15) and KL2x (KL24/25) MCUs built on ARM® Cortex®-M0+ processor.
Features include easy access to MCU I/O, battery-ready, low-power operation, a standard-based form factor with expansion board options and a built-in debug interface for flash programming and run-control.
You can use mbed.org at no charge, with full access to the online SDK, tools and an active community of developers.
- Processor: Freescale KL25Z Kinetis KL2 MCU (MKL25Z128VLK4)
High Performance ARM® Cortex™-M0+ Core
48MHz, 16KB RAM, 128KB FLASH
2xSPI, 2xI2C, 3xUART, 6xPWM, 6xADC, Capacitive Touch Slider and GPIO
- FRDM-KL25Z On-Board Units
MMA8451Q - 3-Axis Accelerometer
PWM Controlled RGB LED
Capacitive Touch Sensor
- Evalution Form Factor
PCB Size: 81mm x 53mm
5V USB Power Supply or 4.5-9V Input (100mA)
Built-in USB drag and drop FLASH programmer
- mbed.org Developer Platform
Advanced C/C++ SDKDocuments:Useful Links
