20A ESC - BRUSHLESS MOTOR DRIVER
  • 20A ESC - BRUSHLESS MOTOR DRIVER
  • 20A ESC - BRUSHLESS MOTOR DRIVER
  • 20A ESC - BRUSHLESS MOTOR DRIVER

20A ESC - BRUSHLESS MOTOR DRIVER

Product Code : 13515 Brand / Origin :  Hobby Wing
Post Comment
Price: 13,44 USD
In Stock : 15
Quantity:
Add to Shopping List
This product rated 4/5 based on 6 customer reviews.


20 A Electronic speed control (Motor Driver) provides you to drive your brushless motors conveniently and safely. This brushles motor driver modul can provide 20 A current continuously and 25 A for max. 10 seconds. It is possible to drive 2 - 12 brushless motor on 210000 rpm - 350000 rpm. Additionally, as the safety mod feature, whereever the throttle lever is, the motor will not start at the first moment.

Product Features:

  • Output: The module can draw 20 A continuously, 25 A for max 10 seconds.
  • Input power: 2 - 3S LiPo Battery, 5 to 9 cells NiMH
  • BEC: 2 A / 5 V linear mod BEC
  • Refresh rate of the throttle signal: 50Hz to 432Hz
  • Max Speed: 210000rpm for 2 Poles BLM, 70000rpm for 6 poles BLM, 35000rpm for 12 poles BLM.(BLM = BrushLess Motor)
  • Size: 42 x 25 x 8 mm
  • Weight: 19 g

Features:
Safety arming feature: Regardless the throttle stick position, the motor will not spin after battery connected.
Throttle calibration function: Throttle range can be calibrated to be compatible with different transmitters.
User programmable.
Multiple program methods supported: transmitter stick, LED Program Card. Very easy to program the ESC at home or at the flying field.
Compatible with Lipo battery and NiCd/NiMH battery.
Internal timing can be changed to be suitable for different brushless motors.
Full protection: Low voltage cutoff protection / Over-heat protection / Throttle signal loss protection.
Microprocessor uses separate voltage regulator IC, with good anti-jamming capability.

Documents:
